A-18 Connectrix DS-32M2 User Guide
Using SNMP to Manage the Switch
Configuration
Group
Configuration group incorporates three scalar MIB variables, a
module table, and a configuration table.
◆ FcFabricName — Name_Identifier of the Fabric to which this
Fabric Element belongs.
◆ FcElementName — Name_Identifier of the Fabric Element.
◆ FcFeModuleCapacity — Maximum number of modules in the
Fabric Element, regardless of their current state.
fcFxPortNxPortName The port name of the attached NxPort, if applicable. If the value of this object is
’0000000000000000’H, this F_Port has no NxPort attached to it.
This is the world wide Name of the attached to NxPort. It’s same as
fcFPortAttachedPortName.
fcFxPortConnectedNxPort The address identifier of the destination F_Port with which this F_Port is currently
engaged in a either a Class 1 or loop connection. If the value of this object is '000000'H,
this F_Port is not engaged in a connection.
This is fixed at ‘000000'H.
fcFxPortBbCreditModel This object identifies the BB_Credit model used by the F_Port. The regular model refers to
the Buffer-to-Buffer flow control mechanism defined in FC-PH [1] is used between the
F_Port and the N_Port. For FL_Ports, the Alternate Buffer-to-Buffer flow control
mechanism as defined in FC-AL [4] is used between the FL_Port and any attached
NL_Ports.
This is fixed at regular(1).
Table A-7 Operation: Fabric Login (continued)
Variable Description
