Product Manager Views
3-19
Product Manager Overview
For details on navigating and monitoring via the Node List view,
refer to Using the Node List View on page 4-17.
Port List View
Clicking the Port List tab on the Product Manager window (refer to
Figure 3-7 on page 3-17) displays a table listing:
◆ Port number
◆ Port name
◆ (S/390 mode only) Port address
◆ Blocked/unblocked configuration
◆ Operating state
◆ Port type
◆ Operating speed
◆ Alert condition
Other options available on the Port List view allow you to:
◆ Block/unblock ports
◆ Display port properties
◆ Display port technology: connector and transceiver types,
distance, media, and speed
◆ Enable Beaconing
◆ Clear Link Incident Alert(s)
◆ Reset the port
For details on these menu options, refer to Port Menu on page 4-14.
For details on navigating and monitoring using the Port List view,
refer to Using the Port List View on page 4-21.
Performance View
Clicking the Performance tab on the Product Manager window (refer
to Figure 3-7 on page 3-17) displays a graphical display of
performance for all ports. (Figure 4-7 on page 4-25 shows an example
of the Performance view. )
The top portion of the Performance view displays bar graphs that
show the level of transmit/receive activity for each port. This
information is updated every five seconds. Each bar graph also
shows the percentage link utilization for the port.
