A
A-20 Connectrix DS-32M2 User Guide
Using SNMP to Manage the Switch
The configuration table displays the configuration parameters of the
F_Ports.
Table A-9 Configuration Table
Variable Provides:
ModuleIndex Module index.
FxPortIndex Port index.
Name Name identifier of the F_Port. Each F_Port has a unique port name in the address space of the fabric.
FC-PHVersHigh Highest or most recent version of FC-PH that the F_Port is configured to support.
FC-PHVersLow Lowest or earliest version of FC-PH that the F_Port is configured to support.
BBCredit Total number of receive buffers available for holding a Class 1 connect-request, or Class 2 or 3 frames
from the attached N_Port. It is for buffer-to-buffer flow control in the direction from the attached N_Port
(if applicable) to the F_Port.
RxBufferSize Largest Data_Field size (in octets) for an FT 1 frame that can be received by the F_Port.
R_A_TOV Resource Allocation Time Out Value configured for the F_Port. This is used as the timeout value for
determining when to reuse an N_Port resource such as a Recovery_Qualifier. It represents E_D_TOV
(see next variable) plus twice the maximum time a frame may be delayed within the fabric and still be
delivered.
E_D_TOV Error detect time out value configured for the F_Port. The Error_Detect_Timeout Value is used as the
timeout value for detecting an error condition.
ClassSvcSupt Value indicating the set of classes of service supported by the F_Port.
IntermixSupt Flag indicating if the F_Port supports an intermixed dedicated connection. The flag is always at no(2).
StackedConMode Value indicating the mode of stacked connect supported by the F_Port. The value is always at none(1).
C2SeqDelivery Flag indicating if Class 2 sequential delivery is supported by the F_Port.
C3SeqDelivery Flag indicating if Class 3 sequential delivery is supported by the F_Port.
HoldTime Maximum time (in microseconds) the F_Port holds a frame before discarding the undeliverable frame.
The value 0 means that the F_Port does not support this parameter.
BaudRate FC-0 baud rate of the F_Port.
Medium FC-0 medium of the F_Port.
TxType FC-0 transmitter type of the F_Port.
Distance FC-0 distance range of the F_Port transmitter.
