A
Fibre Channel Fabric Element MIB Support
A-19
Using SNMP to Manage the Switch
The module table contains the configuration parameters of a port
module.
Table A-8 Module Table
Variable Provides:
fcFeModuleIndex This object identifies the module within the Fabric Element for which this entry contains
information. This value is never greater than fcFeModuleCapacity. This number ranges from 1 to
AS_glob.prod_cnfg_ptr->max_nbr_modules.
fcFeModuleDescr A textual description of the module. This value should include the full name and version
identification of the module. It should contain printable ASCII characters. This string should be
derived from VPD information stored in the FRU EEPROM.
fcFeModuleObjectID The vendor’s authoritative identification of the module. This value may be allocated within the
SMI enterprises subtree (1.3.6.1.4.1) and provides a straight-forward and unambiguous means
for determining what kind of module is being managed. For example, this object could take the
value 1.3.6.1.4.1.99649.3.9 if vendor ’Neufe Inc.’ was assigned the subtree 1.3.6.1.4.1.99649,
and had assigned the identifier 1.3.6.1.4.1.99649.3.9 to its ’FeFiFo-16 PlugInCard. This is a fixed
object identifier assigned from the enterprise subtree (1.3.6.1.4.1.289.2.1.1.2).
fcFeModuleOperStatus This object indicates the operational status of the module: online(1) -- the module is functioning
properly; offline(2) -- the module is not available; testing(3) -- the module is under testing; and
faulty(4) -- the module is defective in some way. The status is evaluated from
fcFPortPhysOperStatus as following order: testing(3): the module is under testing if all four ports
on the current module are testing; faulty(4): the module is defective if any of the ports on the
current module is faulty.
online(1): the module is functioning properly if any of the ports on the current module is online
or testing;
offline(2): the module is not available if any of the ports on the current module is offline.
fcFeModuleLastChange This object contains the value of sysUpTime when the module entered its current operational
status. A value of zero indicates that the operational status of the module has not changed since
the agent last restarted.
This is SS_TIM_RD_TICKS(MILLISEC) * 10
fcFeModuleFxPortCapacity The number of F_Port that can be contained within the module. Within each module, the ports
are uniquely numbered in the range from 1 to fcFeModuleF_PortCapacity inclusive. However,
the numbers are not required to be contiguous. This is
AS_glob.prod_cnfg_ptr->ports_per_module
fcFeModuleName The Name_Identifier of the module. This is the port module world wide name.
