7
Resetting the Configuration
7-19
Using Maintenance Features
3. To continue the reset operation, click Reset on the Reset
Configuration dialog box. If you want to cancel the operation,
click Cancel.
Since the IP address is reset, you may not recover the Ethernet connection to
the switch if you have changed the switch‘s IP addressing from the default
value. In this case you must re-enter the LAN parameters using the operator
panel if you want to continue using the Product Manager.
Table 7-1 lists the default configuration settings.
Table 7-1 Data Default Values
Configuration Description Default
Identification Switch Name NULL string
Switch Description “Fibre Channel Switch”
Switch Contact “End User Contact (please configure)”
Switch Location “End User Contact (please configure)”
Ports Port Names NULL strings
Port Blocked States Unblocked
Extended Distance
(10-100km)
Disabled
LIN Alerts Disabled
Switch Addressing IP Address 10, mac[3], mac[4], mac[5] converted
to word32. MAC addresses are set in
hexidecimal; IP addresses in decimal.
A MAC address of 08 00 88 20 00 57
wil be reset to an IP address of
10.32.0.87.
Subnet Mask 255.0.0.0
Gateway Address 0.0.0.0
MAC Address PROM value
