A
Connectrix Private Enterprise MIB (ef-6000)
A-29
Using SNMP to Manage the Switch
Port Binding Group
Zoning Group
Table A-14 Port Binding Group
Variable Provides:
ef6000PortBindingIndex The fixed port number on the switch. It ranges from 1 to the number of physical ports
that can be supported by the switch.
ef6000PortBindingFlag The flag indicates whether or not Port Binding is in effect for an individual; port. The
values are: yes (1), and no (2).
ef6000PortConfiguredWWN The authorized port WWN for attached servers and storage systems (F ports), or the
authorized switch WWN for attached switches (E ports).
ef6000PortAttachedWWN The WWN of the device currently attached to the port whether it has successfully
connected or is currently being rejected due to a port binding violation.
Table A-15 Zoning Group Table
Variable Provides:
ef6000ActiveZoneSetName The active zone set name.
ef6000ActiveZoneCount The count of zones included in the active zone set.
ef6000DefaultZoneSetState The state of the default zone set.
ef6000ActiveZoneSetState The state of the default zone set.
ef6000HardwareEnforcedZoning Indicates if zoning is hardware enforced (1=Hardzoning, 0=Nameserver zoning only).
Table A-16 Active Zone Table
Variable Provides:
ef6000ZoneIndex Zone index number. This number will range from 1 to the number of zones
specified by the ActiveZoneCount.
ef6000ZoneName The name of the zone.
ef6000ZoneMemberCount The number of members included in the zone.
