EMC Connectrix DS-32M2 - Managing Stored Address Configurations; Address Configuration Library Dialog Box

5
5-22
Connectrix DS-32M2 User Guide
Configuring the Switch
Managing Stored Address Configurations
This operation applies only if the director’s operating mode is set to S/390.
(Refer to Configuring the Operating Mode on page 5-4.)
Address configurations (described under Configuring Port Addresses
on page 5-18) are saved to the Address Configuration Library. This
section describes the procedure to manage address configurations in
the library.
To manage saved library entries:
1. Click Configure on the Product Manager menu bar and select
Addresses on the drop-down menu; then click Stored on the
pop-up submenu.
This displays the Address Configuration Library dialog box
(Figure 5-12).
Figure 5-12 Address Configuration Library Dialog Box
2. Click a row to select a configuration entry. Then click the desired
button:
• Activate — Sends a stored configuration to the switch for
immediate use. (A warning appears before the action occurs.)
If Active=Saved is enabled in through the Configure Management
Server dialog box, this overwrites the current IPL address
configuration.
