11. Chart Alerts
11-5
Areas
To include areas in the chart alert, check the Danger Area box in the Area page of the Plan User Chart dialog box.
Danger Area must checked, otherwise danger areas of a user chart cannot be used in the chart alert. The dangerous
area is drawn in red instead of dark yellow (color may be different depending on Palette in use).
In the Area page, you can
include areas in the chart alert
by checking Danger Area.
The figure below shows the behaviour of a danger symbol, line and area in the chart alert check.
Presentation of
Danger Line
Presentation of
Danger Symbol
Presentation of
Danger Area
