Furuno FEA-2807 - How to Select Datum; How to Select User Chart to Use in Monitoring Mode

15. User Chart Control
15-6
15.3 How to Select Datum
Selection of datum is very important, especially if you manually enter latitude-longitude positions from the control
panel or keyboard or if you use digitizer. If you only use the cursor to add and to modify waypoint locations, then
you could use any datum, although it is recommended to use native datum of the chart.
15.4 How to Select User Chart to use in Monitoring
Mode
The user chart that is selected for the monitoring mode is indicated in the UserChart dialog box (left-click UserChart
in the information area to show). To activate the monitoring mode and select a user chart for the monitoring mode,
do the following:
Put cursor here and
roll scrollwheel to
select User Chart in
Monitor mode
User Chart
Monitor

Plan

X
DISP
DISP
(WT)
