3.13.3 How to Setup the Cellular Modem
By means of the Cellular Modem, it is possible to connect the Voluson E-Series to the Internet by using a
SIM card.
When to use the Cellular Modem
The Cellular Modem is useful if no Internet connection is available via LAN or WIFI. Connecting the Voluson
E-Series to the Internet allows the user to send images via e-mail and/or MMS to patients or physicians.
Note
MMS are sent by e-mail to a 3rd party provider (e.g. SMSglobal). This service needs to be ordered by a 3rd
party provider.
Note
Please check with a Smartphone located near the Voluson E-Series, if network coverage is available. Used
SIM card in the Smartphone should use same provider as SIM card for Cellular Modem.
Hardware Setup: To use the feature the peripheral Cellular Modem needs to be installed and a SIM card from
your local service provider needs to be ordered.
SIM card requirements:
•
Data capable
•
Standard size
•
prepaid or post paid
Note
Since the Voluson E-Series does not enable browser access, the service provider needs to enable the
Internet access on the SIM card before installation in the Cellular Modem. Please ensure from the service
provider, that there is no browser registration necessary when using the SIM card.
Necessary SIM card information provided by the SIM card provider
APN (Access Point Name) e.g., a1.net
User Name for APN e.g., ppp@A1plus.a
Password for APN ***
SIM card Pin ****
Dial in Phone Number e.g., *99# - if not explicitly stated by the provider, use *99#
Please ensure that the SIM card information is available before setting up the Voluson E-Series.
Setup Instructions
3-64
Voluson E-Series Service Manual
5539550APB Revision 6
