4.7 Mechanical Function Checks
4.7.1 Control Console Positioning
The control console can be rotated, translated and adjusted in height (electronically only).
Note For further details refer to Section 5.10.3 on page 5-46 and/or Section 6.3 on page 6-4 .
4.7.2 Brakes and Direction (Swivel) Locks
Check the brakes and swivel locks function as described below.
Table 4-3 Brakes and Direction (Swivel) Lock
Step Task Expected Result(s)
Caster "Steinco" Caster universal "Tente"
1 swivel lock engaged
2
brakes and swivel lock
released
3
brakes and swivel lock
engaged (=full lock)
Functional Checks
Voluson E-Series Service Manual
5539550APB Revision 6
4-25
