8.7 Replacement or Activation of Options
Note
For a list of available SW options and detailed description, refer to Section 5.1.4 "Description of Software
Options" on page 5-12
It might be possible that some probes, options or features are NOT available
•
in some countries.
•
at the time of release of this Service Manual.
8.7.1 How to activate Options by means of a "Demo Key" or a "Permanent Key"
1.
Press the Utilities key on the control console.
2. In the “Utilities” menu touch the
Setup button to invoke the setup desktop on the screen.
3. On the right side of the screen select Administration and then click the Option tab.
Figure 8-20 Setup - Administration - Options page (e.g., Voluson E10)
1 D = Demo (Option is activated for demo and expires at date shown in the "Valid" column)
I = Inactive (Option is not activated)
P = Permanent (Option is permanently activated, i.e.purchased)
d = deactivated (Option is inactive)
2 Permanent Key
4. Position the cursor inside the input field desired and press the right/left trackball key.
5. If one exists, clear/edit the current Permanent Key.
6. Enter the encrypted Permanent Key with the keyboard and click on Submit . (Code will be checked.)
7. Click the Save&Exit button.
Note
After activating a Permanent Key, restart (turn off and on) the Voluson E-Series system.
At EC310 the format of the Permanent key has been changed.
New Format from EC310
onwards: Previous Format still valid until EC300:
e.g., 63XQ-4DE4-Ek1D-A3CFT-JQ0C-YSFF e.g., 02148EBCA0069003EF6F980F
Characters are case sensitive !!
Hyphens (-) must not be entered. They are
self-created.
Characters are not case sensitive.
Replacement Procedures
8-16
Voluson E-Series Service Manual
5539550APB Revision 6
