5.5.1 RTH - Distribution Board USB-Hub
Content in this section
5.5.1.1 RTH6x Function - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-36
5.5.1.2 RTH50 Function - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5-36
5.5.1.1 RTH6x Function
•
USB2.0 Interface, Board is connected to PC via USB cable
•
7 port USB2.0 Hub
•
4 USB Ports for external use
•
1 USB to SATA Converter for DVD Drive
•
2 USB Ports not used
•
Power distribution for Monitor
•
Feed through for DC-Power for the DVD Drive and Fan
5.5.1.2 RTH50 Function
•
USB3.0 Interface, Board is connected to PC via USB cable
•
4 port USB3.0 Hub
•
2 USB3.0 Ports for external use
•
1 USB2.0 to SATA Converter for DVD Drive
•
1 USB3.0 Port to Monitor
•
1 USB3.0 only Port not used below Monitor Connector Plate
•
Power distribution for Monitor
•
Feed through for DC-Power for the DVD Drive
•
Signal switching for UI Brake and Lift
•
Feed through for DC-Power (12V_ATX, 5V_ATX, 5VSB) and Signals (PWR_On, Start_Key, Speaker,
Lifter control, UI_Brake)
5.5.2 RTT - Distribution Board Top
Function of the Distribution Board Top RTT:
•
Feed through for DC-Power (12V_ATX, 5V_ATX, 5VSB) and Signals (PWR_On, Start_Key, Speaker,
Lifter control, UI_Brake)
•
Power distribution for Monitor
•
Power for RTH (Distribution Board Hub)
•
Power for DVD-Drive
•
Signal switching for UI Brake, Lift and Gel warmer
7
7 reserved for the future
