3.6 Printer Installation
Note
For connection schemes see Section 3.5 "Connection of Auxiliary Devices" on page 3-14 .
Content in this section
3.6.1 Installing the Digital Black & White Printer - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-36
3.6.2 Installing the Digital Color Printer - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-36
3.6.3 Installing the DeskJet Color Printer directly via an USB-cable - - - - - - - - - - - - - - - 3-36
3.6.4 Printer Installation manually - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-37
3.6.5 Adjustment of Printer Settings - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-38
3.6.6 Remote Control Selection - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3-41
Note The Network Color Laser printer and the Bluetooth printer connection set MUST NOT be installed by the
user! For installation please contact your local distributor or GE service representative.
If a DeskJet printer (e.g., HP Officejet 100) is connected directly via an USB-cable, use the AC mains power
outlet provided by the Voluson E-Series system (auxiliary output). This ensures medical grade separation
from AC mains.
Warning
After each installation, the leakage currents have to be measured according to IEC 60601-1, IEC 62353 or
other relevant standard.
EC330 (BT18) only:
If the
Whitelisting option is available and activated in System Setup - Administration , a password login
window might appear during the installation procedure.
3.6.1 Installing the Digital Black & White Printer
1.
Power Off/Shutdown the system as described in
Section 4.2.2 on page 4-4 .
2. Connect and install the printer as described in Section 3.5.3 on page 3-17 .
3. Verify correct printer settings; see Section 3.6.5 "Adjustment of Printer Settings" on page 3-38 .
4. Assign the printer to the remote keys P1, P2, P3, P4, P5 and/or P6; see Section 3.6.6 "Remote Control
Selection" on page 3-41 .
3.6.2 Installing the Digital Color Printer
1. Power Off/Shutdown the system as described in Section 4.2.2 on page 4-4 .
2. Connect and install the printer as described in Section 3.5.4 on page 3-19 .
3. Verify correct printer settings; see Section 3.6.5 "Adjustment of Printer Settings" on page 3-38 .
4. Assign the printer to the remote keys P1, P2, P3, P4, P5 and/or P6; see Section 3.6.6 "Remote Control
Selection" on page 3-41 .
3.6.3 Installing the DeskJet Color Printer directly via an USB-cable
1. Power Off/Shutdown the system as described in
Section 4.2.2 on page 4-4 .
2. Connect the printer according to connection scheme Figure 3-17 on page 3-25 .
3. When all cables are connected, press the Power ON button on the printer.
4. Power ON/Boot up the Voluson E-Series system as described in Section 3.4.1 on page 3-9 .
All software drivers are pre-installed for the designated printer only.
5. After physical connection to the Voluson E-Series system, assign the printer to a remote key (P1, P2,
P3, P4, P5 and/or P6) as described in Section 3.6.6 "Remote Control Selection" on page 3-41 .
6. Verify correct printer settings; see Section 3.6.5 "Adjustment of Printer Settings" on page 3-38 .
7. Assign the printer as Report Printer, see Section 3.6.6.1 "Report Printer Selection" on page 3-41 .
Setup Instructions
3-36
Voluson E-Series Service Manual
5539550APB Revision 6
