3.5.9 Connecting a Secondary "Patient" Monitor
Caution
A Secondary "Patient" Monitor MUST NEVER be connected to the Voluson E-Series systems mains supply
directly! Always connect it to an appropriate Isolation Transformer (see
Section 9.10.3 on page 9-42 ).
Caution
The secondary monitor is the only item to be connected to the isolation transformer.
Note
A Secondary Monitor is NOT intended for diagnostic use. It is an additional device used to allow the patient
to watch the proceedings.
Note Take your time to think about the best position of the monitor in your facilities. Patients should be able to
view the monitor easily and without having to bend or turn around.
1. Power Off/Shutdown the system as described in Section 4.2.2 on page 4-4 .
2. Connect the Secondary Monitor according to connection scheme, see: Figure 3-22 on page 3-30 .
3. After physical connection to the Voluson E-Series system check, and if necessary change the Ext.
Monitor Output setting, see: Section 3.7.1.7 on page 3-45 .
Note
Connection is always the same (no differences between PC-Motherboard version of the Voluson E-Series
system).
Setup Instructions
Voluson E-Series Service Manual
5539550APB Revision 6
3-29
