9.2 Parts List Groups
Figure 9-1 Console Views
Table 9-1 Mechanical and user accessible parts
Item Part Group Name Description
100 - "Housing - Mechanical Hardware Parts & Covers" on page 9-4 Housing Covers (except UI and Monitor), Caster
Wheels, Handle
200 - "User Interface" on page 9-9 Console (keyboard, trackball, display, special knobs
and switches) Loudspeakers, Disk Drive, Probe
holder, Console Covers, etc.
300 - "Monitor + Monitor Replacement Parts" on page 9-17 Monitor + Monitor Replacement Parts
400 - "Main Power Modules" on page 9-20 Power Supply Module
500 - Main Board Module
- "FrontEnd (US-Part) Components" on page 9-21
- "BackEnd (PC-Part) Components" on page 9-24
.
Ultrasound (FrontEnd) Components
PC-Part (BackEnd) Components
600 - "Options and Upgrades" on page 9-28 Software Options and Upgrades
700 - "Miscellaneous Cables" on page 9-30
800 - Optional Peripherals and Accessories
- "Printers" on page 9-37
- "Drives and additional Devices" on page 9-39
- "Optional Equipment" on page 9-42
.
DVD recorder and Cable Kits
B/W Printer, Color Printer, DeskJet Printer
USB Stick, HDD Drive, WLAN, etc.
Secondary Patient Monitor, etc.
"System Manuals" on page 9-44
900 - Probes
- "2D-Probes - Curved Array Probes" on page 9-49
- "2D-Probes - Linear Array Probes" on page 9-51
- "2D-Probes - Phased Array Probes" on page 9-52
- "Real-Time 4D Volume Probes" on page 9-53
- "CW-Doppler - Pencil Probes" on page 9-56
950 - "Biopsy Needle Guides" on page 9-57
Renewal Parts
Voluson E-Series Service Manual
5539550APB Revision 6
