GE Voluson E Series User Manual

5.2.1 RTF - Probe Control Board
Switches the Probe Connectors and recognizes Probes
•
Probe Connectors:
-
EC300/EC310 (BT15/BT16):
*
1 CW Pencil-Probe Connector (RSE-board)
*
3 Probe Connectors 408pin
*
1 Dummy-Probe Connector 408pin
-
EC320/EC330 (BT17/BT18):
*
4 Probe Connectors 408pin
•
Probe Select Relays
•
Probe Recognition
5.2.2 RSE - Pencil Probe Board (optional)
This board is not applicable at BT17 (EC320, 17.x.x) and BT18 (EC330, 18.x.x) systems.
Adapter board for connection of CW pencil probes.
Note
The RSE board is required for CW-Option.
5.2.3 RFM - (RF-Interface & Beamformer) FE Mainboard
•
EC300/EC310 (BT15/BT16):
The FrontEnd Mainboard supports Tx/Rx for 128 channels only. To extend to 192 or 256 channels, the
RSX - (Beamformer Receiver/Transmitter) Extension board is required.
•
EC320/EC330 (BT17/BT18):
The FrontEnd Mainboard supports Tx/Rx for 192/256 channels. It does not need RSX Extension board.
5.2.3.1 RFM Board - Interface FPGA
1. DMA logic
2. Beamformer Interface
3. RTF Control Interface
4. RTF FPGA Control Interface
5.2.3.2 RFM Board - Processing FPGA
1. Ultrasound Data Pre-Processing
2. System Control
3. Motor Control
5.2.4 RSX - (Beamformer Receiver/Transmitter) Extension Board
This board is not applicable at BT17 (EC320, 17.x.x) and BT18 (EC330, 18.x.x) systems.
Subset (for RFM) that is required to extend to 192 or 256 channels.
Note
All components of RSX board are also present on RFM - (RF-Interface & Beamformer) FE Mainboard.
Components and Functions (Theory)
5-24
Voluson E-Series Service Manual
5539550APB Revision 6
