3.9.2 Video Specification
Video specifications may be needed to be able to connect laser cameras or other devices to the Voluson E-
Series system.
DVI-D/VGA-connector:
•
visible resolution ... 1280 x 1024
•
screen refresh rate ... 60Hz
S-Video connector:
•
Type: separate Video (Y/C)
•
Video modes: PAL (50Hz), NTSC (60Hz)
3.9.3 External Cables - Maximum Lengths
Table below shows maximum permitted cable length of external cables, according to IEC60601-1-2.
Table 3-15 maximum cable lengths
Description Maximum Cable Length Type
Probe cable 2.5 m shielded
USB cable (port 2.0) 5 m shielded; USB2.0 or higher
USB cable (port 3.0) 2m shielded; USB3.0 or higher
LAN cable 80 m shielded; Cat5e or higher
VGA cable 15 m shielded
S-Video cable 5 m shielded
HDMI cable 10 m shielded
ECG cable 4 m shielded
Power cable 4 m unshielded
PE cable 10 m unshielded
3.10 Available Probes
See
Section 9.12 "Probes" on page 9-49 , for part numbers to be used when ordering new or replacement
service probes.
3.11 Software/Option Configuration
For description refer to:
•
Section 3.7.1 "Setup" on page 3-42
Note For further details refer to the Voluson E-Series Basic User Manual.
Setup Instructions
3-54
Voluson E-Series Service Manual
5539550APB Revision 6
