Table 3-11 USB 3.0 connectors
Pin No Output Signal Description
1 VBus +5V Power
2 USB D- USB 2.0 Data (-)
3 USB D+ USB 2.0 Data (+)
4 GND Ground for power return
5 StdA_SSRX- SuperSpeed receiver
6 StdA_SSRX+ SuperSpeed receiver
7 GND_DRAIN Ground for signal return
8 StdA_SSTX- SuperSpeed transmitter
9 StdA_SSTX+ SuperSpeed transmitter
Table 3-12 S-Video OUT connector (4 pin)
Pin No Output Signal Description
1 SVIDEO OUT/IN YG Y (Luma) GND
2 SVIDEO OUT/IN CG C (Chroma) GND
3 SVIDEO OUT/IN Y Y (Luma) Signal
4 SVIDEO OUT/IN C C (Chroma) Signal
Table 3-13 Monitor Power connector (16 pin)
Pin No Description
2, 3, 7, 10, 15 12V
1, 5, 8, 9, 1116 GND
6 / 14 USB 1- / USB 1+
4, 12, 13 NC (no connection)
Table 3-14 DVI OUT connector
Pin No Description Pin No Description
1 TDMS data 2- 13 TDMS data 3+
2 TDMS data 2+ 14 +5 Volt
3 TDMS data 2, 4 shielding 15 ground for +5 Volt
4 TDMS data 4- 16 Hotplug-Detect
5 TDMS data 4+ 17 TDMS data 0-
6 DDC clock 18 TDMS data 0+
7 DDC data 19 TDMS data 0, 5 shielding
8 Analog: V-Sync 20 TDMS data 5-
9 TDMS data 1- 21 TDMS data 5+
10 TDMS data 1+ 22 TDMS meter shielding
11 TMDS data 1, 3 shielding 23 TDMS clock +
12 TDMS data 3- 24 TDMS clock -
Setup Instructions
Voluson E-Series Service Manual
5539550APB Revision 6
3-53
