The actual location of the test probe may vary by system. Measurements should be recorded for each probe
under the set of test conditions.
Record all data and keep the record of the results with other hard copies of maintenance data.
Table 10-17 Typical Data Format for recording Probe (source) Leakage Current
Unit under Test: Date of Test:
Test Conditions Probe as measured in Saline Bath
System Power Grounding/PE Limit μA
4C-D 11L-D RIC5-9-D
RM6C
off closed 100
off open 500
on closed 100
on open 500
off closed (reversed polarity) 100
off open (reversed polarity) 500
on closed (reversed polarity) 100
on open (reversed polarity) 500
Note
Values in italics font are given as examples only.
Care and Maintenance
Voluson E-Series Service Manual
5539550APB Revision 6
10-21
