Program description - Wing mixers
Model type: "2AIL 2FL"
If servos have been connected to the receiver as
described on page 65 and selected accordingly in the
»Model type« menu, page 105, then the abbrevia-
tions "AILE" and "FLAP" refer to the following flaps:
AI
left
FL
left
FL
right
AI
right
Since the options available on the wing mixer menu
and its sub-menus vary according to the number of
flap servos specified on the »Model type« menu, the
list contains only those set-up options available for
the given model.
Therefore, with a preset to "2AIL 2FL", all options for
setting options for a second set of flap pairs will be
suppressed throughout the (right-side) column la-
beled "FL2".
Fl.pos
Diff.
Ail-tr
Al
Normal AILE
+100%
WK2
FLAP
0%
0%
0%
+100%
0%
+100%
0%
+100%
0%
0%
0%0%
+100%
0%
0%
0%
FL
El
Fl
+100%
+100%
+100%
+100%
0%0%
0%
0%
0%0%
0%
0%
Model type: "2AIL 4FL"
If servos have been connected to the receiver as
described on page 65 and selected accordingly in the
»Model type« menu, page 105, then the abbrevia-
tions "AILE", "FLAP" and "FL2" refer to the following
flaps:
AI
left
FL
left
FL2
left
FL2
right
FL
right
AI
right
Since the options available on the wing mixer menu
and its sub-menus vary according to the number of
flap servos specified on the »Model type« menu, the
list contains only those set-up options available for
the given model.
Fl.pos
Diff.
Ail-tr
AI
Normal AILE
+100%
FL2
FLAP
0%
0%
0%
+100%
0%
+100%
0%
+100%
0%
0%
0%0%
+100%
0%
0%
0%
FL
El
Fl
+100%
+100%
+100%
+100%
0%0%
0%
0%
0%0%
0%
0%
Model type: "4AIL 2FL"
If servos have been connected to the receiver as
described on page 61 and selected accordingly in the
»Model type« menu, page 94, then the abbreviations
"AILE", "AILE2" and "FL" refer to the following flaps:
AI
left
AI2
left
FL
left
FL
right
AI2
right
AI
right
Since the options available on the wing mixer menu
and its sub-menus vary according to the number of
flap servos specified on the »Model type« menu,
page 104, the list contains only those set-up options
available for the given model.
Therefore, with a preset to "4AIL 2FL", all options for
setting options for the first and second set of aileron
pairs as well as those for the flap pair will be dis-
played throughout.
FL.pos
Diff.
Ail-tr.
Al
Normal AILE
+100%
FL
AILE2
0%
+100%
0%
+100%
0%
+100%
0%
+100%
0%
0%
0%0%
+100%
+100%
0%
0%
FL
El
Fl
+100%
+100%
0%
0%
0%0%
0%
0%
0%0%
0%
0%
