266
Program description - Multichannel
–––
SEL Offset
Input 1
Input 2
Input 3
Input 4
fr
fr
fr
–––
–––
–––
+100%
+100%
+100%
+100%
+100%
+100%
+100%
+100%
0%
0%
0%
0%
– travel +
fr
MULTICH 2
Now the desired transmitter control can be selected
with the selection keys on the left or right touch pad.
If the selected control has an assignment, it can be
disconnected from a transmitter control switching its
field to "fr".:
• transmitter control 1 … 4 (CH 1 …4)
• slider control 1 … 3 in the middle of the console
(Sl1 … 3)
• depressible, roller-shaped proportional speed
control (Tv1 … 5)
• side proportional control (Lv1 and Lv2)
(Function inputs "UV1" through "UV8", which are also
in the selection list, can be selected at a later time
and then connected as necessary.)
Note:
If you are using the Nautic-Expert switch
module, No. 4159, any proportional controls
you assign act like switches when close to
their end-points.
"Switch"
Select by the use of the selection buttons the line
over the switch symbol
.
This column is used to assign each of the inputs
used, 1 through 8 (maximum), to any switch available
on the transmitter. These assignments are done as
described in the section “Assigning transmitter con-
trols, switches and control switches” on page 60:
–––
Offset
Input 1
Input 2
Input 3
Input 4
fr
fr
fr
–––
–––
–––
+100%
+100%
+100%
+100%
+100%
+100%
+100%
+100%
0%
0%
0%
0%
– travel +
3
MULTICH 2
Move desired switch
to ON position
(ext. switch: SET)
Any controls which were previously assigned in the
second column will be erased. In this case, instead of
SEL, the switch symbol will be displayed at the
bottom of the 2nd column such that now a second
“normal” switch, or even a transmitter control switch,
logical switch, … can be assigned as needed from
the group of “expanded switches”. In general it is suf-
ficient to assign a simple switch or transmitter control.
–––
Offset
Input 1
Input 2
Input 3
Input 4
fr
fr
fr
–––
–––
–––
+100%
+100%
+100%
+100%
+100%
+100%
+100%
+100%
0%
0%
0%
0%
– travel +
3
MULTICH 2
Erasing transmitter controls or switches
With transmitter control / switch assignment active,
simultaneously pressing the or buttons of
the right-hand four-way button (CLEAR) – see screen-
shots above – resets the corresponding input to “fr”
and “---”.
Column 2, "Control"
–––
SEL Offset
Input 1
Input 2
Input 3
Input 4
fr
fr
fr
–––
–––
–––
+100%
+100%
+100%
+100%
+100%
+100%
+100%
+100%
0%
0%
0%
0%
– travel+
fr
MULTICH 2
Use the arrow keys to move to the column over SEL.
After completing the activation of transmitter control
assignment by tapping the centre SET key of the right
touch pad, the message shown below will appear in
the display:
–––
SEL Offset
Input 1
Input 2
Input 3
Input 4
fr
fr
fr
–––
–––
–––
+100%
+100%
+100%
+100%
+100%
+100%
+100%
+100%
0%
0%
0%
0%
– travel +
fr
MULTICH 2
Move desired
control adj.
Alternatively, the centre SET key of the right touch
pad can be tapped for a second time while this mes-
sage is on display:
