m
m
s
If attached, this display will depict the altitude (in m)
relative to location, starting location as well as the
current rate of ascent/descent (in m/s) from data
originating from the Vario integrated into the
GPS-/Vario module (No. 33600).
Speed display
0
km/h
Subject to availability of the corresponding sensor,
this display visualizes the current speed over ground.
AIR ESC
RX–S QUA: 100%
RX–S ST : 100%
TX–dBm: 33dBm
RX–dBm: 33dBm
RX–SPG.:4.8 TMP
V–PACK: 10ms
CH OUTPUT TYPE:ONCE
RECEIVER
GENERAL
AIR ESC
VARIO
GPS
ELECT. AIR
0
0
0rpm
0.0A
0.0A
0
0mAh
0( 0)°C
0.0V/ 0.0V
0( 0)°C
0( 0)°C
This display visualises the data from a possibly con-
nected to the receiver brushless controller with in-
ternal telemetry with one of the time of the revision
of these instructions current No. 33718-33770 and
33850th
Regardless of any regulator values the operating tem-
perature and the maximum temperature reached in
the current energizing period of a telemetry-capable
electric motor is visualized in the second line of the
display.
It means from top left to bottom right:
Value Explanation
V left value: current battery voltage
Right value: lowest battery voltage in
the current power on time
°C Graphing and left value: current regula-
tor and motor temperature
Value in brackets: maximum ESC and
motor temperature in the current power
on time
mAh current consumed battery capacity in
the actual power on time
A Centre and bar display: actual current
value
Right value: highest power in the actu-
alpower on time
rpm Centre and bar graphic: Current speed
of the connected motor
Right value: the highest speed in the
actual power on time
Rotary speed sensor
U/min
0
0
This display depicts the measured rotary speed of a
connected brushless motor speed controller.
Current and consumption display
0.0A
0.0A
0
0mAh
This display visualises the actually flowing current;
that occurred in the actual power on time so as the
peak current consumed during the same period and
the capacity of the battery connected to the brushless
speed controller.
Voltage, current, speed and temperature display
0.0V
0.0A
0rpm
This display visualizes the actual power supply volt-
age of the motor, the current flowing through the
controller and the speed of the drive motor and left
the operating temperature of the brushless control-
ler and the right temperature of a telemetry-capable
drive motor.
