H3C S7500E Series Command Reference

9-9
Illegal: 0 packet(s)
Sent LACP Packets: 7 packet(s)
Table 9-4 display link-aggregation member-port command output description
Field Description
Flags
One-byte LACP state flags field. From the least to the most significant bit, they
are represented by A through H as follows:
 A indicates whether LACP is enabled. 1 for enabled and 0 for disabled.
 B indicates the timeout control value. 1 for short timeout, and 0 for long
timeout.
 C indicates whether the link is considered as aggregatable by the sending
system. 1 for true, and 0 for false.
 D indicates whether the link is considered as synchronized by the sending
system. 1 for true, and 0 for false.
 E indicates whether the sending system considers that collection of incoming
frames is enabled on the link. 1 for true and 0 for false.
 F indicates whether the sending system considers that distribution of
outgoing frames is enabled on the link. 1 for true and 0 for false.
 G indicates whether the receive state machine of the sending system is using
default operational partner information. 1 for true and 0 for false.
 H indicates whether the receive state machine of the sending system is in the
expired state. 1 for true and 0 for false.
If a flag bit is set to 1, the corresponding English letter that otherwise is not
output is displayed.
Aggregation Interface Aggregate interface to which the current member port belongs
Local Information about the local end
Port Number Number of the port
Port Priority LACP priority of the port
Oper-key Operational key
Flag LACP protocol state flag
Remote Information about the remote end
System ID
System ID of the remote end, comprising the system LACP priority and the
system MAC address
Received LACP Packets Total number of LACP packets received
Illegal Total number of illegal packets
Sent LACP Packets Total number of LACP packets sent
