H3C S7500E Series Command Reference

11-8
Field Description
Transmit Limit The maximum number of packets sent within each Hello time
Protection Type
Protection type on the port, which can be one of the following:
 Root: Root guard
 Loop: Loop guard
 BPDU: BPDU guard
 None: No protection
MST BPDU Format
Format of the MST BPDUs that the port can send, which can be legacy or
802.1s.
Config
indicates the configured value, and
Active
indicates the actual
value.
Port Config-
Digest-Snooping
Indicates whether digest snooping is enabled on the port.
Rapid transition Indicates whether the current port rapidly transitions to the forwarding state.
Num of Vlans Mapped Number of VLANs mapped to the current MSTI
PortTimes
Major parameters for the port:
 Hello: Hello timer
 MaxAge: Max Age timer
 FWDly: Forward delay timer
 MsgAge: Message Age timer
 Remain Hop: Remaining hops
BPDU Sent Statistics on sent BPDUs
BPDU Received Statistics on received BPDUs
MSTI RegRoot/IRPC MSTI regional root/internal path cost
MSTI RootPortId MSTI root port ID
MSTI Root Type MSTI root type, which can be primary root or secondary root
Master Bridge MSTI root bridge ID
Cost to Master Path cost from the MSTI to the master bridge
TC received Number of received TC BPDUs
Protocol Status MSTP protocol status
Protocol Std. MSTP protocol standard
Version MSTP protocol version
CIST Bridge-Prio. The device’s priority in the CIST
