15-2
Untagged Ports:
GigabitEthernet2/0/2 GigabitEthernet2/0/3 GigabitEthernet2/0/4
VLAN ID: 3
VLAN Type: static
Isolate-user-VLAN type : secondary
Route Interface: configured
Description: VLAN 0003
Name: VLAN 0003
Tagged Ports: none
Untagged Ports:
GigabitEthernet2/0/2 GigabitEthernet2/0/3
VLAN ID: 4
VLAN Type: static
Isolate-user-VLAN type : secondary
Route Interface: configured
Description: VLAN 0004
Name: VLAN 0004
Tagged Ports: none
Untagged Ports:
GigabitEthernet2/0/2 GigabitEthernet2/0/4
Table 15-1 display isolate-user-vlan command output description
Field Description
Isolate-user-VLAN VLAN ID Isolate-user-VLAN ID
Secondary VLAN ID Secondary VLAN ID
VLAN Type VLAN type, static or dynamic
Isolate-user-VLAN type Current VLAN type, isolate-user-VLAN or secondary VLAN
Route Interface Whether a VLAN interface is configured for the VLAN
IP Address
IP address of the VLAN interface, if configured. This field is not displayed
if no IP address is configured for the VLAN interface.
Subnet Mask
Subnet mask of the VLAN interface, if configured. This field is not
displayed if no mask is configured for the VLAN interface.
Description VLAN description
Name VLAN name
Tagged Ports Ports through which packets of this VLAN are sent tagged
Untagged Ports Ports through which packets of this VLAN are sent untagged
