20-4
Field Description
Model name Device model
Asset tracking identifier Asset tracking ID
LLDP local-information of port 1 LLDP information to be sent out port 1
Port ID subtype Port ID type, which can be MAC address or interface name
Port ID Port ID, the value of which depends on the port ID subtype
Port description Port description
Management address interface type Numbering type of the interface identified by the management address
Management address interface ID Index of the interface identified by the management address
Management address OID Management address object ID
Port VLAN ID(PVID) Port VLAN ID
Port and protocol VLAN ID(PPVID) Port protocol VLAN ID
Port and protocol VLAN supported Indicates whether protocol VLAN is supported on the port.
Port and protocol VLAN enabled Indicates whether protocol VLAN is enabled on the port.
VLAN name of VLAN 1 Name of VLAN 1
Auto-negotiation supported Indicates whether auto-negotiation is supported on the port.
Auto-negotiation enabled Indicates whether auto-negotiation is enabled
OperMau Current speed and duplex state of the port
PoE supported Indicates whether PoE is supported on the port.
Power port class
PoE device type, which can be :
PSE: power sourcing equipment
PD: powered device
PSE power supported Indicates whether the device can operate as a PSE.
PSE power enabled Indicates whether the device is operating as a PSE.
PSE pairs control ability Indicates whether the PSE-PD pair control is available.
Power pairs
PoE mode, which can be
Signal
(PoE via signal lines) or
Spare
(PoE
via spare lines).
