86 IconMaster Installation and Configuration Manual
Chapter 4: Router Connections
6. Press the right (Enter) button.
7. Use the toggle switch (Nav) to scroll through the parameter list until
IP_Address is highlighted.
8. Press the right (Enter) button.
9. Continue pressing the right (Enter) button until the cursor is under the digit
you want to change.
10. Use the toggle switch (Nav) to change the digit.
11. Press the right (Enter) button to move to the next digit.
12. Repeat the previous three steps until you have changed the IP address.
13. Press the right (Enter) button until the cursor is under the space at the end
of the IP address.
14. Press the left (Esc) button to accept the change.
4. Set the IP Address for the MGI-3903 Module
1. Press the left (Esc) button until the message MGI-3903-R appears on the
VFD display.
2. Press the right (Enter) button.
3. Use the toggle switch (NAV) to scroll through the parameter list until
IP_Address is highlighted.
4. Press the right (Enter) button.
5. Continue pressing the right (Enter) button until the cursor is under the digit
you want to change.
6. Use the toggle switch (Nav) to change the digit.
7. Press the right (Enter) button to move to the next digit.
8. Repeat the previous three steps until you have changed the IP address.
9. Press the right (Enter) button until the cursor is under the space at the end
of the IP address.
10. Press the left (Esc) button to accept the change.
11. Using the IconMaster configuration utility software, set the MKE-3901
reference mode to Composite. (See the IconMaster Configuration Utility
Software Reference Guide for more information.)
5. Set the NSM Card-Edge Parameters
1. Press the left (Esc) button until the NSM message appears on the VFD
display
2. Press the right (Sel) button.
See the Installation and Operation Manual for your NEO
module for more information about setting parameters.
