124 IconMaster Installation and Configuration Manual
Chapter 4: Router Connections
10. On the MKE-3901 back module, connect the Ethernet 1 connection for
MKE-3901 control to a network hub/switch using a straight-through
Ethernet cable.
11. On the MGI-3903 back module, two Ethernet connection options for
MGI-3903 control and logo download as follows:
• To the same network/hub as Ethernet 1 using a normal Ethernet cable.
• To a dedicated switch used for the MGI functionality using a normal
Ethernet cable.
12. Power up the system.
6. Set the IP Address for the MKE-3901 Module
1. Press the left (Esc) button until the message MKE3901 appears on the VFD
display.
2. Press the right (Enter) button.
3. Use the toggle switch (Nav) to scroll through the parameter list until Status
is highlighted.
4. Press the right (Enter) button.
5. Use the toggle switch (Nav) to scroll through the parameter list until Other
is highlighted.
6. Press the right (Enter) button.
7. Use the toggle switch (Nav) to scroll through the parameter list until
IP_Address is highlighted.
8. Press the right (Enter) button.
9. Continue pressing the right (Enter) button until the cursor is under the digit
you want to change.
10. Use the toggle switch (Nav) to change the digit.
11. Press the right (Enter) button to move to the next digit.
12. Repeat the previous three steps until you have changed the IP address.
13. Press the right (Enter) button until the cursor is under the space at the end
of the IP address.
14. Press the left (Esc) button to accept the change.
7. Set the IP Address for the MGI-3903 Module
1. Press the left (Esc) button until the message MGI-3903-R appears on the
VFD display.
2. Press the right (Enter) button.
If you are connecting Ethernet 1 to a network hub/switch, the
IconMaster control panel must be connected to the same
network.
