IconMaster Installation and Configuration Manual 141
Chapter 7: Automation Setup
Ending DVE squeeze preset This should have the same value as the
“Beginning DVE squeeze preset” field
Ending transition or DVE squeeze
duration (mm:ss:ff or S/M/F)
This should have the same value as the
“Beginning transition or DVE squeeze
duration (mm:ss:ff or S/M/F)” field
Horizontal wipe on ending transition? Ignored for ICONMASTER (leave blank)
Vertical wipe on ending transition? Ignored for ICONMASTER (leave blank)
Reverse wipe direction on ending
transition?
Ignored for ICONMASTER (leave blank)
Number of transitions used in effect 2
Effect audio from background (on-air) or
foreground (effect)
B (The
IconMaster does not support
audio from effect sources)
Audio transition is mix (foreground audio
effects)
N (although not used by the
IconMaster
driver, this field may not be left blank)
Audio transition rate (foreground audio
effects only)
Ignored for ICONMASTER (leave blank)
Over mix mixer (blank if not over mix) Ignored for ICONMASTER (leave blank)
Input A duck level (-100 – 0) Ignored for ICONMASTER (leave blank)
Input B over level (0 – 28) Ignored for ICONMASTER (leave blank)
Time before transition to re-route video Ignored for ICONMASTER (leave blank)
Time between effects for DVE transition Ignored for ICONMASTER (leave blank)
Delay before starting 2nd background
effect source
Ignored for ICONMASTER (leave blank)
Delay before starting 3rd background
effect source
Ignored for ICONMASTER (leave blank)
Table 7-6. Effect Transition Settings for IconMaster Entries in
ovrtrans.tbl (Continued)
Field Value
