IconMaster Installation and Configuration Manual 211
Chapter 8: Configuring IconMaster
Changing any of the Transition Cluster functions will require the
replacement of the text film on the corresponding IconMaster
control panel button. See the IconMaster Installation and
Operation Manual for more information.
WARNING
Always ensure that channel buttons are allocated left to
right, with Channel 1 on the left most button of Cluster 1.
Table 8-10. Button Clusters, Functions, and Selections
Button Group Function Selections
Cluster 1 and Cluster 2 Frame Select CH 1, CH 2, CH 3, CH 4, CH 5,
CH 6, CH 7
GPO Output control GPO1, GPO2, GPO3, GPO4,
GPO5, GPO6, GPO7, GPO8,
GPO9, GPO10, GPO11, GPO12,
GPO13
Quick Selects QS 1, QS 2, QS 3, QS 4, QS 5, QS
6, QS 7, QS 8
Fast Reset
(cluster 2)
SET, CLEAR, RECALL (appear in
Parameter Adjustment Control
cluster)
Clocks & Timers TIMER, CLOCK
Fade to Silence SIL
Fade to Black FTB
Transition Cluster Transition Rates SLOW, MED, FAST, CUT
Breakaway AUDIO, VIDEO
Automation Hold HOLD
Effects FX
Fade Types TAKEFADE, FADETAKE,
FADEFADE, CROSSFADE
Machine Control CUE, FF, MARK, PLAY, REW,
STOP
None None
