214 IconMaster Installation and Configuration Manual
Chapter 8: Configuring IconMaster
Configurable cluster 2 Fast Reset System Configuration (page 197)
Parameter adjustment control
cluster
Source Select (SRCSEL) Primary Inputs (page 157)
Keyer control (KEYER) Keyer (page 183)
Transition control (TRANS) Transition (page 169)
Audio control (AUDIO) Audio Configuration (page 160)
Effects control (FX) Effects (page 171)
Quick Selects (Q-SEL) Quick Selects (page 176)
Aux bus Preconfigured auxiliary bus preview
(AUX)
Aux Bus (page 165)
Program bus) PGM Primary Inputs (page 157)
System Configuration (page 196)
PST (Preset) bus PST Primary Inputs (page 157)
System Configuration (page 196)
Configurable transition functions Hold Button Configuration (page 210)
Transition Rate
Slow
Medium
Fast
Cut
Transition (page 169)
Button Configuration (page 210)
Breakaway
Audio
Video
Button Configuration (page 210)
Transition Effects
FX
Effects (page 171)
Button Configuration (page 210)
Transition Type
Take-fade
Fade-take
Fade-fade
Cross-fade
Transition (page 169)
Button Configuration (page 210)
Machine Control Type
Cue
FF
Mark
Play
Rewind
Stop
Machine control (page 184)
Button Configuration (page 210)
Table 8-11. Busses, Functions, and Configuration Utilities Relationships (Continued)
Control Panel Item Functions Setup Information
