12 IconMaster Installation and Configuration Manual
Chapter 2: Installation
Scenario 1: All Components Ordered at the Same Time and
Preinstalled; Internal (NSM) Routers
Step Explained
1. Mount the control panel(s) into a desktop or a rack
page 23
2. Connect the control panel to another device
page 28
3. Install NEO frame into a rack
page 37
4. Configure NSM modules
page 77
5. Attach breakout modules
page 43
6. Connect the NEO modules to another device
page 38
7. Check card-edge parameters are set to your preferences
page 69
8. Configure IconMaster control panel
page 147
9. Initialize IconMaster
page 126
10. Customize push buttons on control panel
page 63
Scenario 2: All Components Ordered at the Same Time and
Preinstalled; External Router
Step Explained
1. Mount the control panel(s) into a desktop or a rack
page 23
2. Connect the control panel to another device
page 28
3. Install NEO frame into a rack
page 37
4. Mount external router into a rack (see specific router manual)
5. Configure external router
Panacea
Platinum
page 91
page 116
6. Attach breakout modules
page 43
7. Connect the NEO modules to another device
page 38
8. Check card-edge parameters are set to your preferences
page 69
9. Configure IconMaster control panel
page 147
10. Initialize IconMaster
page 126
11. Customize push buttons on control panel
page 63
