IconMaster Installation and Configuration Manual 13
Chapter 2: Installation
Scenario 3: All Components Ordered at the Same Time and
Preinstalled; Platinum Router, CENTRIO. eBox
Step Explained
1. Mount the control panel(s) into a desktop or a rack
page 23
2. Connect the control panel to another device
page 28
3. Install NEO frame into a rack
page 37
Mount Platinum router into a rack (see Platinum Installation, Configuration, and
Operation Manual)
4. Configure eBox
page 121
5. Configure Platinum
page 121
6. Configure CENTRIO
page 121
7. Attach breakout modules
page 43
8. Connect the NEO modules to another device
page 38
9. Check card-edge parameters are set to your preferences
page 69
10. Configure IconMaster control panel
page 147
11. Initialize IconMaster
page 126
12. Customize push buttons on control panel
page 63
Scenario 4: Audio Control Panel Ordered Separately, All Other
Components Ordered at the Same Time and Preinstalled; Internal
(NSM) Routers
Step Explained
1. Connect main control panel to audio control panel
page 21
2. Mount the control panel(s) into a desktop or a rack
page 23
3. Connect the control panel to another device
page 28
4. Install NEO frame into a rack
page 37
5. Configure NSM modules
page 77
6. Attach breakout modules
page 43
7. Connect the NEO modules to another device
page 38
8. Check card-edge parameters are set to your preferences
page 69
9. Configure IconMaster control panel
page 147
10. Initialize IconMaster
page 126
11. Customize push buttons on control panel
page 63
