14 IconMaster Installation and Configuration Manual
Chapter 2: Installation
Scenario 5: Audio Control Panel Ordered Separately, All Other
Components Ordered at the Same Time and Preinstalled; External
Router
Step Explained
1. Connect main control panel to audio control panel
page 21
2. Mount the control panel(s) into a desktop or a rack
page 23
3. Connect the control panel to another device
page 28
4. Install NEO frame into a rack
page 37
5. Mount external router into a rack (see specific router manual)
6. Configure external router
Panacea
Platinum
page 91
page 116
7. Attach breakout modules
page 43
8. Connect the NEO modules to another device
page 38
9. Check card-edge parameters are set to your preferences
page 69
10. Configure IconMaster control panel
page 147
11. Initialize IconMaster
page 126
12. Customize push buttons on control panel
page 63
Scenario 6: Audio Control Panel Ordered Separately, All Other
Components Ordered at the Same Time and Preinstalled; Platinum
Router, CENTRIO, eBox
Step Explained
1. Connect main control panel to audio control panel
page 21
2. Mount the control panel(s) into a desktop or a rack
page 23
3. Connect the control panel to another device
page 28
4. Install NEO frame into a rack
page 37
5. Mount Platinum router into a rack (See Platinum Installation, Configuration,
and Operation Manual)
6. Configure eBox
page 121
7. Configure Platinum
page 121
8. Configure CENTRIO
page 121
9. Attach breakout modules
page 43
10. Connect the NEO modules to another device
page 38
11. Check card-edge parameters are set to your preferences
page 69
12. Configure IconMaster control panel
page 147
13. Initialize IconMaster
page 126
14. Customize push buttons on control panel
page 63
