18 IconMaster Installation and Configuration Manual
Chapter 2: Installation
8. Configure external router
Panacea
Platinum
page 91
page 116
9. Attach breakout modules
page 43
10. Connect the NEO modules to another device
page 38
11. Check card-edge parameters are set to your preferences
page 69
12. Configure IconMaster control panel
page 147
13. Initialize IconMaster
page 126
14. Customize push buttons on control panel
page 63
Scenario 13: Audio Control Panel Ordered Separately, Fader Bar
Ordered Separately, Optional Modules Ordered Separately; Platinum
Router, CENTRIO, eBox
Step Explained
1. Install fader bar
page 64
2. Connect main control panel to audio control panel
page 21
3. Mount the control panel(s) into a desktop or a rack
page 23
4. Connect the control panel to another device
page 28
5. Install NEO options into NEO frame
page 35
6. Install NEO frame into a rack
page 37
7. Install CENTRIO into Platinum router (see CENTRIO Installation,
Configuration, and Operation Manual)
8. Mount Platinum router into a rack
(See Platinum
Installation and
Operation
Manual)
9. Configure eBox
page 121
10. Configure Platinum
page 116
11. Configure CENTRIO
page 121
12. Attach breakout modules
page 43
13. Connect the NEO modules to another device
page 38
14. Check card-edge parameters are set to your preferences
page 69
15. Configure IconMaster control panel
page 147
16. Initialize IconMaster
page 126
17. Customize push buttons on control panel
page 63
Scenario 12: Audio Control Panel Ordered Separately, Fader Bar
Ordered Separately, Optional Modules Ordered Separately; External
Router
Step Explained
