Graphics
If the polygon definition cros~e8 over itself, the areas are defined in alternate order.
Figure D-IO. Overlapping Polygon Area Fills
Examp1 e: Move the pen to 33 0, and define and fill a pentagon 100 units on a side. Lift and
move the pen to 40 10, and define another pentagon inside the first pentagon.
Ec * p a 5 33,0 133,0 166,95 83,150 0,95
a 40,10 12,91 83,138 153,91 125,10 T
Figure 0-11. Polygon Area Fili Example
Area Boundary Pen
You can outline a filled area with a solid white line by enabling the area boundary pen. When
the area boundary pen is disabled, the edges of the filled area are the same pattern as the
interior.
Set Area Boundary Pen: Ec* m<boundary pen>h
where <boundary pen> may be:
o= enable boundary pen
Any other integer = disable boundary pen
No parameter = disable boundary pen
D-22
