HP P2000 Reference Guide

370 XML API basetype properties
remote-addresses
Properties
Example
# show replication-volumes
...
<OBJECT basetype="remote-addresses" name="remote-address" oid="2" format="rows">
<PROPERTY name="connected-ports" type="string">B1</PROPERTY>
<PROPERTY name="remote-address" type="string">10.134.101.172:3260</PROPERTY>
</OBJECT>
...
Table 51 remote-addresses properties
Name Type Description
connected-ports string • port-IDs: For a remote primary or secondary volume, the IDs of up to two
hosts ports in the local system that are connected to the remote system. If two
ports are connected but only one is shown, this indicates that a problem is
preventing half the available bandwidth from being used.
• N/A: For a local primary or secondary volume.
remote-address string The address of each host port in the remote system through which the volume is
accessible.

HP P2000 Specifications

General

Drive Support	SAS
Controller	Dual Controller options available
Host Interface	6Gb SAS, 8Gb FC, 1Gb iSCSI
RAID Levels	RAID 0, 1, 5, 6, 10
Storage Type	SSD
Hot-swappable Components	Drives, controllers, power supplies, fans
Dimensions	8.9 x 44.8 x 63.5 cm (3.5 x 17.6 x 25 inches)
Drive Bays	Up to 12 LFF or 24 SFF drive bays per enclosure
