406 XML API basetype properties
system-parameters-table
Properties
Table 75 system-parameters-table properties
Name Type Description
ulp-enabled string Shows whether the system is using Unified LUN Presentation (ULP).
• true: ULP is enabled.
profiles-
enabled
string Shows whether host profiles are enabled, which determines whether LUN 0 can
be assigned to volume mappings.
• true: Host profiles are enabled.
• false: Host profiles are disabled.
max-ports uint32 Number of host-interface ports in the controller enclosure.
max-drives uint32 Number of disks that the system supports.
max-volumes uint32 Number of volumes that the system supports.
max-vdisks uint32 Number of vdisks that the system supports.
max-luns uint32 Number of LUNs that the system supports.
max-owned-
arrays-per-
controller
uint32 Number of vdisks that each controller supports.
max-capi-arrays uint32 Same as max-vdisks.
max-chunk-size uint32 Maximum chunk size for vdisks: 64 KB.
min-chunk-size uint32 Minimum chunk size for vdisks: 16 KB.
physical-
position-offset
uint32 Starting index for physical components (enclosures, disks, etc.) in the storage
system.
backoff-
percentage
uint32 Percentage of disk capacity that is reserved to compensate for minor capacity
differences between disk drives so they can be used interchangeably. This is not
settable by users. The default is 1 percent.
metadata-size uint32 Amount of metadata, in blocks, stored on each disk.
local-
controller
string Controller you are currently logged in to.
• A: Controller A.
• B: Controller B.
local-
controller-
numeric
string Numeric equivalents for local-controller values.
• 0: B
• 1: A
serial-number string Last five digits of the midplane serial number.
external-
targetid-
control
string Not used.
external-
targetid-
control-numeric
string Not used.
lan-heartbeat string Not used.
lan-heartbeat-
numeric
string Not used.
