HP P2000 Reference Guide

400 XML API basetype properties
snapshot-with-retention-tasks
Properties
Example
# show tasks
...
<OBJECT basetype="snapshot-with-retention-tasks" name="task-snapshow-with-retention"
oid="2" format="pairs">
<PROPERTY name="master-volume-name" type="string">vd01_v002</PROPERTY>
<PROPERTY name="master-volume-serial" type="string">SN</PROPERTY>
<PROPERTY name="snapshot-prefix" type="string">SnapSet001</PROPERTY>
<PROPERTY name="retention-count" type="uint32">1</PROPERTY>
<PROPERTY name="last-created" type="string"></PROPERTY>
</OBJECT>
...
Table 70 snapshot-with-retention-tasks properties
Name Type Description
master-volume-
name
string Source volume name.
master-volume-
serial
string Source volume serial number.
snapshot-prefix string A label to identify snapshots created by this task. Snapshot names have the
format prefix_s#, where # starts at 001.
retention-count uint32 Number of snapshots to retain with this prefix, from 1 to 32.
last-created string Name of the last snapshot created by the task, or blank.

HP P2000 Specifications

General

Drive Support	SAS
Controller	Dual Controller options available
Host Interface	6Gb SAS, 8Gb FC, 1Gb iSCSI
RAID Levels	RAID 0, 1, 5, 6, 10
Storage Type	SSD
Hot-swappable Components	Drives, controllers, power supplies, fans
Dimensions	8.9 x 44.8 x 63.5 cm (3.5 x 17.6 x 25 inches)
Drive Bays	Up to 12 LFF or 24 SFF drive bays per enclosure
