HP P2000 G3 MSA System CLI Reference Guide 387
elem-status string The SES status that corresponds to the PHY status.
• Disabled: Critical condition is detected.
• Error: Unrecoverable condition is detected. Appears only if there is a
firmware problem related to PHY definition data.
• OK: Element is installed and no error conditions are known.
• Non-critical: Non-critical condition is detected.
• Not Used: Element is not installed in enclosure.
• Unknown: Either:
• Sensor has failed or element status is not available. Appears only if an
I/O module indicates it has fewer PHYs than the reporting I/O module,
in which case all additional PHYs are reported as unknown.
• Element is installed with no known errors, but the element has not been
turned on or set into operation.
elem-status-
numeric
string Numeric equivalents for elem-status values.
• 0: Error
• 1: OK
• 2: Disabled
• 3: Non-critical
• 4: Error
• 5: Not Used
• 6: Unknown
• 7: Unknown
• 8: Unknown
elem-disabled string • Enabled: PHY is enabled.
• Disabled: PHY is disabled.
elem-disabled-
numeric
string Numeric equivalents for elem-disabled values.
• 0: Enabled
• 1: Disabled
elem-reason string More information about the status value.
• Blank if status is OK.
• Error count interrupts: PHY disabled because of error-count
interrupts.
• Externally disabled: PHY disabled externally via serial debug port.
• PHY control: PHY disabled by a SES control page as a result of action by
a Storage Controller or user.
• Not ready: PHY is enabled but not ready. Appears for SC-1 PHYs when
the partner I/O module is not installed. Appears for Drive, SC-1, or Ingress
PHYs when a connection problem exists such as a broken connector.
• Firmware reboot
• Drive removed: PHY disabled because drive slot is empty.
• Unused - disabled by default: PHY is disabled by default because
it is not used.
• Excessive PHY changes: PHY is disabled because of excessive PHY
change counts.
Table 62 sas-status-controller-a properties (continued)
Name Type Description
