7-64
Wireless Security Configuration
Web Authentication for Mobile Users
When using Web-Auth, users must disable any proxy server for their web
browser.
Note After successfully authenticating using Web-Auth, the user may experience
“Page Not Found” (timeout) errors when attempting to re-access the Web-
Auth home page. To work around this browser cache expiration problem,
restart the browser.
Configuration Summary
Configuring the AP-530 to provide mobile clients with Web-Auth requires
several steps:
1. Configure the WLAN-SSID and VLAN ID (as described in Chapters 5 and
6).
2. Optionally, configure static WEP or WPA-PSK security (as described in
“Establishing Security” on page 7-16).
3. Specify the RADIUS server that will authenticate registered users and the
global guest user account (as described in “Configuring RADIUS Client Authenti-
cation” on page 7-32).
4. Configure the Web-Auth guest credentials if you are using Guest Login.
5. Configure the Web-Auth temporary IP address pool.
6. Configure Web-Auth for the WLAN.
a. Select a login type: User Login, Guest Login, or both.
b. Specify the redirect URL and retry limit.
c. Accept the default screen fields or customize them for your environ-
ment.
d. Enable Web-Auth.
Web: Configuring the Global Address Pool
The Web Authentication screen shown in Figure 7-17 configures the range of
temporary IP addresses reserved for Web-Auth users.
You can modify these parameters:
Starting IP Address: Specifies the first IP address in the range of
temporary IP address to be assigned to the Web-Auth temporary address
pool.
Subnet Mask: Specifies the subnet mask that defines the extent of the
range of IP address in the address pool.
