Special Features
Wireless Distribution System (WDS) and Spanning Tree Protocol (STP)
Note Spanning Tree Protocol (STP) has detected a loop and the WDS 1 interface is
being blocked by STP, as shown in the following example.
ProCurve Access Point 530(wds1)#show wds 1
WDS #1
Description Wireless Distribution System - Link 1
Status Enabled Use Radio 1
Local MAC 00:14:C2:A5:22:61 Remote MAC 00:14:C2:A4:14:A0
STP State blocking WDS SSID WDS SSID 1
Security Type no-security (from WLAN 1)WEP Key Type hex
WEP Key not set WEP Key Size 128bit
WPA Key not set
Bytes Rx 7140 Bytes Tx 76
Packets Rx 66 Packets Tx 1
Compressed Rx 0 Compressed Tx 0
Mcast packets Rx 0 Carrier errors Tx 0
Dropped Rx packets 0 Dropped Tx packets 0
FIFO overflows Rx 0 FIFO overflows Tx 0
Frame errors Rx 0 Packet collisions Tx 0
Total Rx errors 0 Total Tx errors
ProCurve Access Point 530(wds1)#
