4-30
Using the ProCurve Web Browser Interface
Tasks for Your First ProCurve Web Browser Interface Session
To Set IP Parameters i:
1. Select Ethernet.
2. To set a dynamic connection, select DHCP in the Connection Type drop-
down.
3. To set a manual connection, select Static IP in the Connection Type drop-
down.
4. If you chose Static IP, enter the IP address and the subnet mask in the Static
IP Address and Subnet Mask fields. The defaults automatically populate.
5. If a management station exists on another network segment, in the Default
Gateway field enter the IP address of a gateway that can route traffic between
these segments.
6. Enter the IP address for the primary and secondary DNS servers to be used
for host-name to IP address resolution.
7. Optionally enter the domain suffix for hostname/domain-name lookups
in the Domain field.
8. Click
[Update] to save these IP settings.
Note If you change the IP address using the Web interface, you must log in again
using the new address.
