17-19 Operators’ Manual
990400 Rev C 2010 May 1
2-10
System Labels
The following labels are attached to the system.
Label Definition and Location Symbol Definition
Patient Emergency Stop Panel Label
Location: Can either be hung from the chair support
mechanism or held in the Patient’s hand.
Indicator Panel Label
Location: Front Overhead
PANEL ONLY TO BE REMOVED BY ISI TRAINED
SERVICE PERSONNEL
Location: Beam Limiter Panel
To Next Page
