D-1
990400 Rev C 2010 May 1
Appendix
D
System Labels
English
Symbol Descriptions Locations Symbol Descriptions Locations
Emergency Stop Patient Emergency
Stop, Control Box
Maximum Lifting
Capacity
Chair Assembly
General Warning Control Box, X-Ray
Source, Gantry,
Chair Assembly,
Rear Overhead,
Chair Gate, X-Ray
Power Supply
X-Ray On
X-Ray On Lamp
Fuse
Control Box, Front
Overhead
Rear Overhead
Laser X-Ray Source,
Gantry, Patient
Alignment Panel
Pinch Point Seat Assembly,
Chair Gate
Power Control Box, Front
Overhead
Warning Electrical
Hazard
Rear Overhead
Ready Control Box, Front
Overhead
Type B (Body)
applied part
complies with IEC
60601-1
Rear Overhead
Seat Weight Seat Assembly Non-Ionizing
Radiation
Rear Overhead
Fault Control Box, Front
Overhead
Recycle Rear Overhead
Warning Ionizing
Radiation
Control Box Chair Cable Rear Overhead
Follow Operating
Instructions for Use
Control Box Control Box Cable Rear Overhead
X-Ray Radiation Control Box Interlock Cable Rear Overhead
Turns Unit On
Turns Unit Off
Start the Scan
Control Box
Warning Cable Rear Overhead
Seat Height
Adjustment
Patient Alignment
Panel
Network Cable to
Workstation
Computer Cable
Rear Overhead
