17-19 Operators’ Manual
990400 Rev C 2010 May 1
16-6
Remote System Export (RSSM)
VisionQ enables DICOM images to be transferred from the VisionQ
to a remote system, such as a Picture Archive and Communications
System (PACS). The Remote Service Send Module (RSSM) enables
the transfer using DICOM storage protocol (C-STORE). RSSM
continuously monitors the local folder that is setup to receive the
images to be exported. When DICOM images are exported to the
folder, RSSM transfers them to the user-defined remote destination.
RSSM Installation and Setup
1. Place the RSSM.exe in the same folder where the VisionQ.exe
resides.
2. Double-click RSSM.exe. The DICOM Send Module is
displayed.
RSSM
VisionQ
(2) “Send to Remote”
command issued
(3) DICOM files
saved to disk
(4) DICOM files
transferred to
remote system
(1) Continuous
monitoring
To Next Page
