990400 Rev C 2010 May 1
4-1
Chapter
4
System Startup and
Shutdown
System Startup
The System includes the Scanner and a Computer Workstation. The
system is available for use immediately after System Startup, no device
warmup is required. Both units must be ON to function properly. To start
the system, do the following:
1. Power up the Scanner: press the ON button on the Main
Control Box. The POWER indicator on the Main
Control Box and Scanner should light.
2. Power up Computer Workstation: press the power
button on the front of the Workstation. The computer
boots and loads the operating system.
3. Launch VisionQ Software: double-click the VisionQ
icon on Workstation desktop. The VisionQ software
application is launched.
NOTE: Although the system is now ready to scan, the Ready
indicator does not illuminate until the Acquire button is pressed to start a
scan.
System Shutdown
The Scanner and Computer Workstation are powered independently. Both
units are powered OFF as described below.
NOTE: It is recommended that the VisionQ application be closed at the end
of each business day.
To shut down the system:
1. From the Main menu on the Computer Workstation, select
File > Exit. VisionQ closes but the Windows desktop remains ON.
