iZ Technology Corporation
(IF AES CARD PRESENT)
These settings allow verification of incoming AES-specific
data, and set output emphasis to On or Off.
This dialogue reads the indicator flag for the selected
input pair. Use the and keys to select an
AES/EBU input pair with a valid signal and the sample
rate will be displayed in the dialogue.
In the early days of digital, emphasis was used to
artificially boost the level of high frequency signal content
so that it could be quantized at a higher resolution. The
EMPHASIS IN dialogue indicates if the incoming AES
signal is using emphasis or not.
Use this dialogue to turn the emphasis flag on and off for
the AES output signal. When it is turned on it indicates to
the receiving device that the digital audio stream has
been recorded with emphasis and it should be decoded
accordingly.
Since RADAR does not decode emphasis nor store the
emphasis flag for audio recorded with emphasis, the
emphasis flag should be turned ON if the digital audio
recorded has previously been encoded with emphasis.
Emphasis is rarely, if ever, used in the industry today and
these options are included primarily for dealing with
legacy recordings.
The number of channels supported by the installed card.
For RADAR this value will always be 24 channels.
AES SETTINGS:
MULTI-CHNL TYPE
AES SETTINGS:
EMPHASIS OUT
AES SETTINGS:
EMPHASIS IN
AES SETTINGS:
SAMPLE RATE IN
MAIN/I/O MENU:
AES SETTINGS
