MANUAL ADDENDUM
RADAR VERSION 3.
5
3
CONDITION CAUSE SOLUTIO N
No signal on analogue output – Faulty cable or incorrect pin
out
– RADAR Sync not locked
– See Wiring Diagrams on
www.izcorp.com
– If Sync light is flashing, check sync
source, or set RADAR as master
No signal on digital output – Faulty cable or incorrect pin
out
– RADAR Sync not locked
– See Wiring Diagrams on
www.izcorp.com
– If Sync light is flashing, check sync
source, or set RADAR as master
Pop and clicks on ins/outs – RADAR Sync not locked or
faulty
– Not enough ventilation for
RADAR
– If Sync light is flashing, check sync
source, or set RADAR as master
– Allow adequate airflow and cooling for
RADAR
Can’t mount Recording Drive – Drive not inserted
– Drive not locked
– RADAR not set to mount that
SCSI ID
– Drive has failed
– Check to see that LED beside the
drive is a solid 0 or 1, and lock the key
– Check the
MODE display ID # on
RADARView™ is set to the same ID #
as the drive
–
MAIN MENU/DIAGNOSTICS/SCAN
SCSI BUS
Is the hard drive detected
on the correct ID#?
Flashing red timecode or ERR
in Session Controller display
– Recording drive is not rated
for high sample rate
– External SCSI device faulty
– Drive is failing
– Verify using an iZ Technology
recording drive qualified for the project
sample rate
– Remove all other SCSI devices except
for current recording drive
– Replace drive
XXX kHz Illegal message – The incoming AES s ource
doesn’t indicate the sample
rate which causes RADAR to
mistakenly display a
XXXkHz
ILLEGAL
error message
–
MAIN MENU / PREFS
MENU/IGNORE AES FLAGS
Enabling the IGNORE AES FLAGS will
remove this error message
Can’t mount network drive – Bad or incorrect Ethernet
cable
– Incorrect networking settings
– Firewall or other security
blocking access
– Verify using correct cable by checking
that the LEDs on the network card are
lit
– See Support Documents on
www.izcorp.com
for setup
– Turn off firewall or other security
programs
